Ferrum Audio HYPSOS – Hybrid Power Supply Dual Output

With the Dual Output version, Ferrum Audio takes its acclaimed hybrid power supply to the next level. Designed for sophisticated systems where multiple components demand uncompromising power quality—such as the Ferrum OOR and Ferrum WANDLA—HYPSOS Dual Output delivers exceptional performance with added flexibility.

Thanks to its two DC outputs, HYPSOS can power two devices simultaneously, provided they share the same voltage requirements. No external splitter, no cable clutter—just a clean, elegant solution with maximum upgrade potential.

Sound: Detailed, Dynamic, Effortless

HYPSOS is known for its extremely stable and ultra-clean power delivery. The result is a sound signature that is highly resolving and dynamic, yet natural and fatigue-free. Microdetail, spatial precision and transient speed all benefit from the refined power architecture.

With Sweet Spot Tuning (SST), the output voltage can be fine-tuned—even on the fly—to find the optimal sonic balance for your specific setup. Combined with 4-Terminal Sensing Design (4TSD) and Spread Spectrum Mode, HYPSOS offers genuine sound optimization potential for discerning listeners.

Hybrid Power System

The linear/switching hybrid design combines the strengths of both technologies:

• Extremely low ripple and noise
• Fast transient response
• High efficiency

The advanced 4TSD cable design uses two conductors for power delivery and two for voltage feedback. This ensures the exact voltage level directly at the DC input of the connected device, effectively compensating for cable resistance and significantly improving transient response.

Dual Output – Greater System Flexibility

• Two DC outputs with shared voltage
• Up to 80 W continuous power (combined)
• Up to 6 A continuous current (combined)
• Ideal for powering OOR & WANDLA or two devices with identical voltage requirements
• 4TSD functionality active on the main output

HYPSOS Dual Output eliminates the need for external splitters and integrates seamlessly into high-end desktop or rack-based systems.

Universal & Future-Proof

• Wide continuous output voltage range: 5–30 V
• Pre-configured device profiles or fully manual setup
• Automatic Transformer Voltage Adjust (ATVA)
• Electronic output polarity switch
• Overvoltage, current limit and short-circuit protection

Advanced automation features include Trigger in/out connectivity and compatibility with Apple TV remotes, allowing convenient system integration and standby control.

Included in the Box

• HYPSOS Dual Output
• High-quality DC cable (5.5 × 2.5 mm or 5.5 × 2.1 mm plug)
• Mains cable (EU, UK, AU or US)
• Custom DC plugs available upon request

Technical Specifications

• Power input: 110–120 V / 220–240 V AC (EU/US) 100 V AC (JP)
• DC output voltage: 5–30 V (shared across both outputs)
• Max. continuous output power: 80 W (combined)
• Max. continuous output current: 6 A (combined)
• Dimensions (W × D × H): 21.7 × 20.6 × 5 cm
• Net weight: 3.05 kg

In the box

• 1x Ferrum HYPSOS Dual Output hybrid power system
• 1x power cord
• 1x spare fuse
• 1x DC cord 50 cm (plug fitted to order)

HYPSOS Dual Output is more than an update—it is a meaningful evolution. For systems running two high-performance components, it provides a refined, powerful and elegant power solution that elevates overall system performance in a clearly audible way.
