Ferrum Audio Hypsos Hybrid Power Supply

Ferrum Audio HYPSOS – Hybrid Power Supply

With HYPSOS, Ferrum Audio introduces an entirely new category of hi-fi component. Far more than a conventional power supply, HYPSOS is designed as an integral part of a high-end audio system — a component that directly influences performance, dynamics, and tonal refinement.

Built around a software-controlled architecture with minimal hardware dependency, HYPSOS remains flexible, future-proof, and ready for firmware enhancements.

Hybrid Power System

At the heart of HYPSOS lies its innovative linear/switching hybrid topology.

This design combines:

• The ultra-low ripple and noise characteristics of a linear power supply
• The fast transient response and efficiency of a modern switching design

The result is a power delivery system that is exceptionally stable, clean, and dynamically responsive.

Wide Voltage Range – Maximum Versatility

HYPSOS offers:

• Continuously adjustable output voltage from 5–30 V
• Up to 6 A continuous current (below 13.3 V)
• Up to 80 W continuous output power
• 9 A maximum impulse current

Users can select from a list of pre-configured device profiles or manually define custom parameters. This makes HYPSOS one of the most universal high-performance DC power supplies available.

Sweet Spot Tuning (SST)

HYPSOS allows precise fine-tuning of the output voltage — even while the device is operating.

This enables direct listening comparisons and makes it possible to identify the optimal voltage “sweet spot” for connected equipment. Adjustments are safe and seamlessly executed in real time.

4T Sensing Design (4TSD)

The proprietary four-terminal sensing system ensures that the exact voltage is delivered at the DC input of the powered device.

Two conductors supply power, while two additional conductors provide continuous voltage feedback. This compensates for cable resistance and eliminates voltage drops under load, significantly improving transient response and overall stability.

Advanced Automation

HYPSOS integrates effortlessly into modern audio systems:

• Apple TV remote compatibility
• Trigger In/Out connectivity
• Automatic power-up functionality, even for devices without dedicated trigger inputs

Comprehensive Safety Features

• Automatic Transformer Voltage Adjust (ATVA)
• Electronic Output Voltage Polarity Switch
• Overvoltage, current limit, and short-circuit protection

These systems ensure safe and reliable operation at all times.

Sound Performance

HYPSOS enhances an existing audio setup by delivering a cleaner, more controlled power foundation.

Audible improvements often include:

• Tighter, more structured bass
• Greater midrange clarity
• Increased air and refinement in the treble
• Improved micro- and macro-dynamics

With Sweet Spot Tuning, 4T Sensing, and Spread Spectrum Mode, users can tailor performance to their personal preferences and system synergy.

Included Accessories

• HYPSOS Hybrid Power Supply
• High-quality DC cable with either 5.5 × 2.5 mm or 5.5 × 2.1 mm plug
• Mains cable (US/EU/UK depending on version)

Custom DC cables are available upon request.

Technical Specifications (Excerpt)

• AC Input: 110–120 V / 220–240 V AC, 50–60 Hz
• Output Voltage Range: 5–30 V DC
• Max Continuous Output Current: 6 A
• Max Continuous Output Power: 80 W
• Maximum Impulse Current: 9 A
• Dimensions (W × D × H): 217.5 × 206.5 × 50 mm
• Weight: approx. 2.89 kg

In the box

• 1x Ferrum HYPSOS hybrid power system
• 1x power cord
• 1x spare fuse
• 1x DC cord 50 cm (plug fitted to order)
